Electrical system |
controller |
AC asynchronous controller EVC550-5230 (Haiger) |
|||
Battery |
8 maintenance-free traction batteries 3EVF-200AH (3hr) (Xupai) |
||||
Motor |
Special AC asynchronous motor 48V/5KW (Weihai Liyuan, Depuda) |
||||
Charger |
Computerized intelligent car charger 48V/25A, charging time <8 hours (Weihai Tianli) |
||||
DC Converter |
High-power isolation DC converter 48V/12V-500W (Xiamen DIS) |
||||
Body configuration |
Front shield and wiper |
Automotive laminated glass, wiper blades |
|||
Roof |
Metal stamping one-time forming |
||||
Cushion |
Four-angle adjustable luxury PU fabric seat/(optional bus seat) |
||||
Floor |
Anti-slip floor leather |
||||
Body |
The body is a one-piece metal stamping shell, and the entire vehicle is pickled, phosphated, and cathodic electrophoresed. also beautiful and durable,lightweight and other unique advantages. | ||||
Chassis |
National standard steel, one-piece bending, shot blasting and plastic spraying |
||||
rearview mirror |
Adjustable for each hand、foldable exterior rearview mirror. |
||||
Led light signal |
Headlights, turn signals, reversing lights, brake lights、fog light |
||||
police equipment |
Standard police light with shouting function and USB external amplifier function |
||||
Dashboard |
Blister foam molding instrument panel, electric vehicle combination meter, electric lock switch, combination switch, dual-speed wiper switch | ||||
steering system |
Two-way rack and pinion steering system, automatic gap compensation function, EPS electric power assist |
||||
Brake system |
Front disc and rear drum + hydraulic dual-pipeline braking system, vacuum electronic assist + handbrake parking |
||||
suspension system |
Front MacPherson independent suspension,leaf springs with dampers |
||||
audio speaker |
USB playback host can be plugged in and dual speakers,Whistler, reversing reminder buzzer. |
||||
wheel |
165/70R13C+ wheel cover |
||||
Technical parameters |
length*width*height |
3900*1650*2110±5(mm) | curb weight |
1250kg | |
Rated number of passengers (people) |
2 | Fire warehouse size |
1950*1450*1300±5(mm) | ||
Maximum driving speed |
≤30km/h | Water tank capacity |
1000(L) | ||
Driving range |
≥90km | minimum ground clearance |
≥150mm | ||
Maximum grade |
≤20% | Wheelbase |
2800±5(mm) | ||
Slope holding performance |
20% | Wheelbase (front/rear) |
front1420mm/rear1420（mm） | ||
Minimum turning radius |
≤5.2m | braking distance |
≤5m | ||
Braking stability |
1.9m | Energy consumption per 100 kilometers |
8kwh | ||
Optional parts |
Additional parts, LED display screen + 500RMB, reversing driving recorder + 500 RMB, aluminum alloy wheels + 500 RMB, car electric fan + 200 RMB. If other configurations are required, please contact us. |
||||
