Electrical system |
controller |
AC asynchronous controller |
|||
Battery |
Maintenance-free traction battery 3EVF-200AH 12 pieces |
||||
Motor |
Special AC asynchronous motor 72V/7.5KW |
||||
Charger |
Computerized intelligent car charger 72V/25A, charging time <8 hours |
||||
DC Converter |
High power isolated DC converter 72V/12V-500W |
||||
Body configuration |
Front shield and wiper |
Automotive laminated glass, wiper blades |
|||
Roof |
Metal stamping one-time forming |
||||
Cushion |
luxury PU fabric seat |
||||
Floor |
Pattern aluminum floor |
||||
Body |
The body is a one-piece metal stamping shell, and the entire vehicle is pickled, phosphated, and cathodic electrophoresed. also beautiful and durable,lightweight and other unique advantages. |
||||
Chassis |
National standard steel, one-piece bending, shot blasting and plastic spraying |
||||
rearview mirror |
Adjustable for each hand、foldable exterior rearview mirror. |
||||
Led light signal |
Headlights, turn signals, reversing lights, brake lights、fog lights |
||||
police equipment |
Standard police light with shouting function and USB external amplifier function |
||||
Dashboard |
Blister foam molding instrument panel, electric vehicle combination meter, electric lock switch, combination switch, dual-speed wiper switch | ||||
steering system |
Two-way rack and pinion steering system, automatic gap compensation function, EPS electric power assist |
||||
Brake system |
Front disc and rear drum + hydraulic dual-pipeline braking system, vacuum electronic assist + handbrake parking |
||||
suspension system |
Front MacPherson independent suspension,leaf springs with dampers |
||||
audio speaker |
USB playback host can be plugged in and dual speakers,Whistler, reversing reminder buzzer. |
||||
wheel |
165/70R13C+ wheel cover | ||||
Technical parameters |
length*width*height |
4490*1550*2200±5(mm) | curb weight |
1520kg | |
Rated number of passengers (people) |
2 | Vehicle load | 2000kg | ||
Maximum driving speed |
≤30km/h | Water tank capacity |
1500L | ||
Driving range |
≥90km | minimum ground clearance |
≥150mm | ||
Maximum grade |
≤20% | Wheelbase |
2300±10(mm) | ||
Slope holding performance |
20% | Wheelbase |
front1390mm/rear1420（mm） | ||
Minimum turning radius |
≤5.2m | braking distance |
≤5m | ||
Braking stability |
1.9m | Energy consumption per 100 kilometers |
8kwh | ||
| Energy consumption per 100 kilometers | 8kwh | Braking stability | 1.9m | ||
| Optional parts | 1、Heating and cooling air conditioner 3,000 yuan 2、Aluminum alloy wheels 500 yuan 3、Driving recorder 500 yuan 4、LED display 500 yuan 5、electric high pressure pump 3500 yuan 6、500Lstainless steel water tank 2,000 yuan 7、Firefighting tools 1,000 yuan |
||||
